Standard Circular Electric Cylinder SDB Series
Standard Circular Electric Cylinder SDB Series
Standard motor: servo 7.5KW, 11KW, 15KW, 22KW
Repeat accuracy: ±0.02(mm)
Screw lead: 20(mm)
Maximum speed: 500(mm/s)
Maximum load: 20T(kg)
Standard effective stroke: 50~1000(mm)
